This product has been discontinued and removed from our shelves.
| A | E | C | D | Drill pipe | ||
| System No. | Outer Dia. | Thickness Range |
Reamed Dia. | Min. Inner Dia. of Casing Shoe | Hammer Type | Drill Pipe Range |
| KE85 | 108mm (4.25") |
9-15mm (0.35")-(0.59") |
118mm (4.65") |
86mm (3.4") |
DHD3.5, COP32, COP34 | 76mm (3") |
| KE90 | 114mm (4.5") |
11-13mm (0.43")-(0.51") |
127mm (5") |
91mm (3.6") |
DHD 3.5, COP32 COP34 |
76mm (3") |
| KE102 | 127mm (5") |
11mm-13mm (0.43")-(0.51") |
136mm (5.35") |
101mm (3.97") |
DHD 3.5, COP32 COP34 |
76mm (3") |
| KE115 | 140mm (5.5") |
13mm-16mm (0.51")-(0.63") |
152mm (5.98") |
117mm (4.6") |
DHD340, QL 40 SD-4 |
76mm (3") |
| KE115A | 146mm (5.75") |
14mm-19mm (0.55")-(0.75") |
154mm (6") |
117mm (4.6") |
DHD340, QL 40, SD-4 COP 42/44 |
76mm (3") |
| KE140 | 168mm (6.6") |
13mm-19mm (0.51")-(0.75") |
184mm (7.25") |
140mm (5.5") |
DHD350, QL50 / SD-5 COP52/54 |
76mm-89mm (3")-(3.5") |
| KE150 | 178mm (7") |
13mm-19mm (0.51")-(0.75") |
194mm (7.63") |
150mm (5.90") |
DHD350, QL50 / SD-5 | 76mm-89mm (3")-(3.5") |
| KE165 | 193mm (7.6") |
13mm-20mm (0.51")-(0.78") |
206mm (8.11") |
16 5mm (6.5") |
DHD360, QL60 / SD-6 | 89mm-114mm (3.5")-(4.5") |
| KE190 | 219mm (16.5") |
13mm-20mm (0.51")-(0.78") |
234mm (9.21") |
193mm (7.6") |
DHD360 QL60, SD-6 |
89mm-114mm (3.5")-(4.5") |
| KE210 | 245mm (9.64") |
14mm-21mm (0.55")-(0.85") |
260mm (10.25") |
210mm (8.25") |
DHD360/380, QL 60/80 SD-6/SD-8 |
114mm (4.5") |
| KE240 | 273mm (10.75") |
16mm-22mm (0.63")-(0.83") |
300mm (11.8") |
24 0mm (9.5") |
DHD380, QL80 SD-8 |
114mm-127mm (4.5")-(5") |
