6'' DTH Bits

6" BIT Data Referenced By MD65 Concave Face Bit

  • Specification Of Products: MD65
  • Specification Of Products: M60A
  • Specification Of Products: SD6
  • Specification Of Products: QL60
Diameter No. × Button diameter mm Button angle° Flushing
holes 		Weight
(Kg) 		Part No
mm inch Gauge Buttons Front Buttons
152 6 8×18 4×16+4×14 38 2 23 MD65-152
154 6 8×18 4×16+4×14 38 2 23 MD65-154
156 6 1/4 8×18 4×16+4×16 38 2 23 MD65-156
159 6 1/4 8×18 4×16+4×16 38 2 23.5 MD65-159
165 6 1/2 8×18 4×16+4×16 38 2 24 MD65-165
171 6 3/4 8×18 8×16 38 2 25 MD65-171
178 7 8×18 6×16+4×16 38 2 26 MD65-178
185 7 1/4 9×18 6×16+4×16 38 2 26.8 MD65-185
190 7 1/2 10×18 8×16+5×16 38 2 27.5 MD65-190
203 8 10×18 8×16+6×16 38 2 31 MD65-203
6'' DTH Bits
